Panel mount RFID reader

Industrial RFID tag reader IND-TAB supports transponders in the many standards. The robust housing with IP65 rating makes the device perfect for industrial applications. Wide application is possible due to the use of a number of network protocols, including Modbus TCP and also Modbus RTU protocol.

COMMUNICATION

LAN port and RS485 port are used for communication with the device.

There are a number of protocols to choose from:

• HTTP in server mode,
• HTTP in client mode,
• Modbus TCP,
• SNMP,
• Modbus RTU,
• ICMP
• Web browser, with built-in Web server.

APPLICATION

Equipping reader with two relay outputs and two inputs allows its wide application. In industrial conditions it can be a tool to control the efficiency of the production process or employees. The programmer can take full control over the reader, define the functions of the three signaling diodes and the buzzer, read the state of outputs and inputs, and subordinate its operation to its application. The reader is equipped with an internal real time clock that can be synchronized using the SNTP protocol. The internal memory of the device gives the ability to assign cards to specific users (Users) and Master cards with broader privileges. When the Logging function is enabled, the ID numbers of all read tags are stored in the memory.

TECHNICAL DATA

POWER

• Power supply voltage: 10-24VDC or PoE 802.3af

• Power consumption: max 2,5W ( ~200mA@12V)


COMMUNICATION

• Ethernet

• RS485


TRANSPONDER AND MEMORY

• Tag reading distance: up to 8cm from the front of the device (LED side),
• Memory of the ID numbers: 1 000,
• Memory of the events: 30 000,
• Defining access hours for 4 groups of ID numbers,
• Assign names to ID numbers.

INPUTS

• 2 digital inputs


OUTPUTS

• 2 relay outputs
